12A 250VAC 8Pin Screw-in relay base RYF08A2 Manufacturer of the Industrial Control Products RY-ELE

Characteristics

Rated Current: Up to 12A at 250VAC, ideal for medium to high load control
Installation method: Direct screw-in wiring
Ambient Operating Temperature: -35°C to +70°C, suitable for harsh industrial environments
Withstand Voltage: Up to 2000VAC, ensuring electrical safety and reliability
Weight: Approx. 36g, lightweight yet rugged in design

Place of Origin:

China

Payments:

T/T

Lead Time:

To be negotiated

shipping:

Express · Ocean freight · Land freight · Air freightreight

Customization:

Customized logo (Min. Order: 2000 sets)

Model Number:

RYF08A-PU

Brand Name:

RY-ELE

Inquiry

Write a Review

Key Technical Features:

The RYF08A2 is an 8-pin DIN rail mount relay socket with screw-in terminal technology, designed for fast, secure, and tool-free wiring. It supports a wide range of plug-in relays including 2-pole (DPDT) models such as RXS2C, RYER2N, and others using the same 8-pin layout.

Rated Current: Up to 12A at 250VAC, ideal for medium to high load control
Installation method: Direct screw-in wiring
Ambient Operating Temperature: -35°C to +70°C, suitable for harsh industrial environments
Withstand Voltage: Up to 2000VAC, ensuring electrical safety and reliability
Weight: Approx. 36g, lightweight yet rugged in design

Product Display

carousel-2

ryf08a2-relay-socket-for-ry-series-relay

carousel-5

ryf08a2-relay-socket-with-screw-terminal

RYF08A-PU（套组）（白底） (4)

ryf08a2-relay-base-for-automation-control

RYF08A-E（黑+灰）

ryf08a2-industrial-relay-mounting-socket

RYF08A2（4个）

ryf08a2-relay-socket-for-24vdc-and-220vac-relays

RYF08A2（6个）

Structural & Functional Advantages

ryf08a2-relay-socket-for-electromechanical-relays

12A 250VAC 8Pin Screw-in relay base RYF08A2 Manufacturer of the Industrial Control Products RY-ELE 13

Screw-In Wiring

Direct wire insertion saves time and eliminates the need for screwdrivers—perfect for mass production or field retrofitting.

8-Pin Relay Compatibility

Works with standard 2Z (DPDT) relays like RXS2C, RYER2N, and similar 8-pin units.

DIN Rail Mounting

Quick and secure mounting on 35mm DIN rail, widely used in control cabinets and PLC enclosures.

Maintenance-Friendly

Supports easy relay replacement without disturbing wiring; push button or tool slot may be included for quick wire release.

Application Scenario

12A 250VAC 8Pin Screw-in relay base RYF08A2 Manufacturer of the Industrial Control Products RY-ELE 17

Industrial Control Systems

PLCs, motor controls, and automation equipment

12A 250VAC 8Pin Screw-in relay base RYF08A2 Manufacturer of the Industrial Control Products RY-ELE 18

Electrical Panels

Distribution boards and power supply units

Building Automation

Lighting control, HVAC systems, and security systems

Home Appliances

Wiring for household devices and equipment

FAQ

What type of relays are compatible with the RYF08A2 socket?

The RYF08A2 socket supports 8-pin screw-in relays, especially 2-pole changeover (DPDT) types such as RXS2C, RYER2N, or other relays with a compatible 8-pin footprint.

What does “2” mean in the model name?

"2" means the shell plastic material is of different grades and contains secondary materials.

Is it DIN rail mountable?

Yes. The RYF08A2 is designed for quick snap-on mounting to standard 35mm DIN rails, ideal for control panels and modular relay racks.

Can I replace the relay without rewiring?

Absolutely. The relay is screw-in type, and the socket allows you to replace the relay without disturbing the wiring, making maintenance fast and safe.

Does it include surge protection or LED indication?

The base model does not include built-in protection or LEDs, but optional relay modules or external accessories can provide these functions as needed.
